STEELS

STAINLESSSTEELS

CAST IRON

HIGHTEMPALLOYS

TITANIUM

HARDENEDSTEELS

NON-FERROUS

PLASTICS/COMPOSITES

193

www.kyocera-sgstool.com

1

•

1L

•

1EL

FRACTIONAL SERIES

inch

EDP NO.

SERIES

CUTTING

DIAMETER

D

1

LENGTH

OF CUT

L

2

OVERALL

LENGTH

L

1

SHANK

DIAMETER

D

2

UNCOATED

UNCOATEDW/

FLAT

Ti-NAMITE

(TiN)

Ti-NAMITE-C

(TiCN)

Ti-NAMITE-A

(AlTiN)

Ti-NAMITE-A

(AlTiN)

W/FLAT

Di-NAMITE

®

(Diamond)

1/64 1/32 1-1/2 1/8

30101

–

39101

39001

30191

–

–

1

1/32 5/64 1-1/2 1/8

30103

–

39103

39003

30192

–

–

1

3/64 7/64 1-1/2 1/8

30105

–

39105

39005

30193

–

–

1

1/16 3/16 1-1/2 1/8

30107

–

39107

39007

30194

–

91268

1

5/64 3/16 1-1/2 1/8

30109

–

39109

39009

30195

–

–

1

3/32 9/32 1-1/2 1/8

30111

–

39111

39011

30196

–

–

1

7/64 3/8 1-1/2 1/8

30113

–

39113

39013

30197

–

–

1

1/8 3/8 1-1/2 1/8

30177

–

39177

39077

30029

–

–

1

*1/8 1/2 1-1/2 1/8

30115

–

39115

39015

30198

–

91272

1

1/8 3/4 2-1/4 1/8

33141

–

31727

31737

31747

–

–

1L

1/8

1

3

1/8

33143

–

31860

31870

31880

–

–

1EL

9/64 1/2

2

3/16 30117

–

39117

39017

30199

–

–

1

5/32 1/2

2

3/16 30119

–

39119

39019

30000

–

–

1

11/64 5/8

2

3/16 30121

–

39121

39021

30001

–

–

1

*3/16 5/8

2

3/16 30123

–

39123

39023

30002

–

91276

1

3/16 3/4 2-1/2 3/16 33101

–

31728

31738

31748

–

–

1L

3/16 1-1/8 3

3/16 33121

–

31861

31871

31881

–

–

1EL

13/64 5/8 2-1/2 1/4

30125

–

39125

39025

30003

–

–

1

7/32 5/8 2-1/2 1/4

30127

–

39127

39027

30004

–

–

1

15/64 3/4 2-1/2 1/4

30129

–

39129

39029

30005

–

–

1

*1/4 3/4 2-1/2 1/4

30131

30300

39131

39031

30006

–

91280

1

1/4 1-1/8 3

1/4

33103

–

31729

31739

31749

–

–

1L

1/4 1-1/2 4

1/4

33123

–

31862

31872

31882

–

–

1EL

17/64 3/4 2-1/2 5/16 30133

–

39133

39033

30007

–

–

1

9/32 3/4 2-1/2 5/16 30135

–

39135

39035

30008

–

–

1

19/64 13/16 2-1/2 5/16 30137

–

39137

39037

30009

–

–

1

*5/16 13/16 2-1/2 5/16 30139

–

39139

39039

30010

–

91284

1

5/16 1-1/8 3

5/16 33105

–

31730

31740

31763

–

–

1L

5/16 1-5/8 4

5/16 33125

–

31863

31873

31883

–

–

1EL

21/64 1 2-1/2 3/8

30141

–

39141

39041

30011

–

–

1

continued on next page

FRACTIONAL

4 Flute End Mills

POS

4

TOLERANCES

(inch)

D

1

=

+0.0000/–0.0020

D

2

=

h

6

For patent

information visit

www.ksptpatents.com
