220 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
220
www.kyocera-sgstool.com
5M
•
5XLM
METRIC SERIES
mm
EDP NO.
SERIES
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1,0
4,0
38,0
3,0
40505
48756
48778
48799
5M
1,5
4,5
38,0
3,0
40509
48757
48779
48800
5M
2,0
6,3
38,0
3,0
40513
48758
48780
48801
5M
2,5
9,5
38,0
3,0
40517
48759
48781
48802
5M
3,0
12,0
38,0
3,0
40521
48760
48782
48803
5M
3,0
25,0
75,0
3,0
43501
49466
49479
49492 5XLM
3,5
12,0
50,0
4,0
40525
48761
48783
48804
5M
4,0
14,0
50,0
4,0
40529
48762
48784
48805
5M
4,0
25,0
75,0
4,0
43503
49467
49480
49493 5XLM
4,5
16,0
50,0
6,0
40533
48763
48785
48806
5M
5,0
16,0
50,0
6,0
40537
48764
48786
48807
5M
5,0
25,0
75,0
5,0
43507
49469
49482
49495 5XLM
6,0
19,0
50,0
6,0
40541
48765
48787
48808
5M
6,0
25,0
75,0
6,0
43505
49468
49481
49494 5XLM
7,0
19,0
63,0
8,0
40545
48766
48788
48809
5M
8,0
20,0
63,0
8,0
40549
48767
48789
48810
5M
8,0
25,0
75,0
8,0
43515
49470
49483
49496 5XLM
9,0
22,0
75,0
10,0
40553
48768
48790
48811
5M
10,0
22,0
75,0
10,0
40557
48769
48791
48812
5M
10,0
38,0
100,0
10,0
43525
49471
49484
49497 5XLM
11,0
25,0
75,0
12,0
40561
48770
48792
48813
5M
12,0
25,0
75,0
12,0
40565
48771
48793
48814
5M
12,0
50,0
100,0
12,0
43535
49472
49485
49498 5XLM
12,0
75,0
150,0
12,0
43545
49473
49486
49499 5XLM
14,0
32,0
89,0
14,0
40569
48772
48794
48815
5M
14,0
75,0
150,0
14,0
43555
49474
49487
49500 5XLM
16,0
32,0
89,0
16,0
40573
48773
48795
48816
5M
16,0
75,0
150,0
16,0
43565
49475
49488
49501 5XLM
18,0
38,0
100,0
18,0
40577
48774
48796
48817
5M
18,0
75,0
150,0
18,0
43575
49476
49489
49502 5XLM
20,0
38,0
100,0
20,0
40581
48775
48797
48818
5M
20,0
75,0
150,0
20,0
43585
49477
49490
49503 5XLM
25,0
38,0
100,0
25,0
40585
48776
48798
48819
5M
25,0
75,0
150,0
25,0
43595
49478
49491
49504 5XLM
METRIC
3 Flute Square End
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
POS
3
For patent
information visit
www.ksptpatents.com
