METRIC
Plastic Composite
Series
29M
Metric
Ap
Ae
Ae
Vc
(m/min)
Diameter (D
1
)
(mm)
Ae x D
1
Ap x D
1
3
6
8
10
N
CFRP, AFRP
(CARBON FIBER,
ARAMID FIBER)
Slot
1
≤ 1
120
RPM
12722
6361
4771
3817
(96-164)
Fr
0.061
0.122
0.163
0.203
Feed (mm/min)
776
776
776
776
Profile
≤ 0.5
≤ 1.5
150
RPM
15903
7951
5963
4771
(120-180)
Fr
0.061
0.122
0.163
0.203
Feed (mm/min)
970
970
970
970
HSM
≤ 0.05
≤ 2
250
RPM
26504
13252
9939
7951
(200-300)
Fr
0.140
0.280
0.373
0.467
Feed (mm/min)
3710
3710
3710
3710
GFRP
(FIBERGLASS)
Slot
1
≤ 1
100
RPM
10602
5301
3976
3181
(80-120)
Fr
0.061
0.122
0.162
0.203
Feed (mm/min)
646
646
646
646
Profile
≤ 0.5
≤ 1.5
120
RPM
12722
6361
4771
3817
(96-164)
Fr
0.061
0.122
0.163
0.203
Feed (mm/min)
776
776
776
776
HSM
≤ 0.05
≤ 2
200
RPM
21203
10602
7951
6361
(160-240)
Fr
0.140
0.280
0.374
0.467
Feed (mm/min)
2970
2970
2970
2970
CARBON, GRAPHITE
Slot
1
≤ 1
145
RPM
15372
7686
5765
4612
(116-174)
Fr
0.095
0.190
0.253
0.317
Feed (mm/min)
1460
1460
1460
1460
Profile
≤ 0.5
≤ 1.5
185
RPM
19613
9807
7355
5884
(148-222)
Fr
0.095
0.190
0.253
0.317
Feed (mm/min)
1863
1863
1863
1863
HSM
≤ 0.05
≤ 2
300
RPM
31805
15903
11927
9542
(240-360)
Fr
0.219
0.437
0.583
0.729
Feed (mm/min)
6957
6957
6957
6957
PLASTICS
Slot
1
≤ 1
245
RPM
25974
12987
9740
7792
(196-294)
Fr
0.037
0.075
0.100
0.125
Feed (mm/min)
974
974
974
974
Profile
≤ 0.5
≤ 1.5
305
RPM
32335
16168
12126
9701
(244-366)
Fr
0.038
0.075
0.100
0.125
Feed (mm/min)
1213
1213
1213
1213
HSM
≤ 0.05
≤ 2
505
RPM
53538
26769
20077
16062
(404-606)
Fr
0.088
0.175
0.233
0.292
Feed (mm/min)
4685
4685
4685
4685
HSM (high speed machining)
finish cuts typically required reduced feed and cutting depths
rpm = (Vc x 1000) / (D
1
x 3.14)
rates shown are for use without coolant; rates may be increased with coolant
mm/min = Fr x rpm
dust collection is vital when machining dry
adjust parameters based on resin type and fiber structure
diamond coating will increase tool life in graphite and composite materials
reduce speed when overheating causes melting or damage to resin
refer to the KYOCERA SGS Tool Wizard
®
for complete technical information
reduce feed if delamination or fraying occur
(www.kyocera-sgstool.com)
