361 / 396
ROUTERS
ROUTERS
361
www.kyocera-sgstool.com
METRIC
Carbon Composite
Series
20M
Metric
Ap
Ae
Ae
Vc
(m/min)
Diameter (D
1
)
(mm)
Ae x D
1
Ap x D
1
3
6
8
10
12
N
CFRP, AFRP
(CARBON FIBER,
ARAMID FIBER)
Slot
1
≤ 1
120
RPM
12722
6361
4771
3817
3181
(96-164)
Fr
0.055
0.113
0.243
0.366
0.439
Feed (mm/min)
700
720
1160
1395
1395
Profile
≤ 0.5
≤ 1.5
150
RPM
15903
7951
5963
4771
3976
(120-180)
Fr
0.055
0.113
0.243
0.366
0.439
Feed (mm/min)
875
900
1450
1744
1744
HSM
≤ 0.05
≤ 2
250
RPM
26504
13252
9939
7951
6626
(200-300)
Fr
0.126
0.260
0.556
0.833
1.000
Feed (mm/min)
3350
3450
5527
6625
6625
GFRP
(FIBERGLASS)
Slot
1
≤ 1
100
RPM
10602
5301
3976
3181
2650
(80-120)
Fr
0.054
0.111
0.236
0.357
0.428
Feed (mm/min)
570
587
940
1135
1135
Profile
≤ 0.5
≤ 1.5
120
RPM
12722
6361
4771
3817
3181
(96-164)
Fr
0.054
0.111
0.236
0.357
0.428
Feed (mm/min)
684
704
1128
1362
1362
HSM
≤ 0.05
≤ 2
200
RPM
21203
10602
7951
6361
5301
(160-240)
Fr
0.124
0.261
0.557
1.011
1.213
Feed (mm/min)
2629
2765
4430
6430
6430
CARBON, GRAPHITE
Slot
1
≤ 1
145
RPM
15372
7686
5765
4612
3843
(116-174)
Fr
0.069
0.152
0.323
0.482
0.579
Feed (mm/min)
1061
1165
1860
2224
2224
Profile
≤ 0.5
≤ 1.5
185
RPM
19613
9807
7355
5884
4903
(148-222)
Fr
0.069
0.152
0.323
0.482
0.579
Feed (mm/min)
1353
1486
2373
2838
2838
HSM
≤ 0.05
≤ 2
300
RPM
31805
15903
11927
9542
7951
(240-360)
Fr
0.159
0.348
0.740
1.109
1.331
Feed (mm/min)
5057
5535
8820
10580
10580
PLASTICS
Slot
1
≤ 1
245
RPM
25974
12987
9740
7792
6494
(196-294)
Fr
0.069
0.150
0.319
0.477
0.572
Feed (mm/min)
1792
1945
3107
3717
3717
Profile
≤ 0.5
≤ 1.5
305
RPM
32335
16168
12126
9701
8084
(244-366)
Fr
0.069
0.150
0.319
0.477
0.572
Feed (mm/min)
2231
2421
3868
4627
4627
HSM
≤ 0.05
≤ 2
505
RPM
53538
26769
20077
16062
13385
(404-606)
Fr
0.159
0.344
0.732
1.097
1.316
Feed (mm/min)
8513
9220
14690
17617
17617
HSM (high speed machining)
finish cuts typically required reduced feed and cutting depths
rpm = (Vc x 1000) / (D
1
x 3.14)
rates shown are for use without coolant; rates may be increased with coolant
mm/min = Fr x rpm
dust collection is vital when machining dry
adjust parameters based on resin type and fiber structure
diamond coating will increase tool life in graphite and composite materials
reduce speed when overheating causes melting or damage to resin
refer to the KYOCERA SGS Tool Wizard
®
for complete technical information
reduce feed if delamination or fraying occur
(www.kyocera-sgstool.com)
