Z1MB
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-X
(TX)
JetStream
3,0
8,0
57,0
6,0
46354
–
4,0
11,0
57,0
6,0
46355
–
5,0
13,0
57,0
6,0
46356
–
6,0
13,0
57,0
6,0
46343
–
8,0
19,0
63,0
8,0
46344
–
10,0
22,0
72,0
10,0
46345
–
12,0
26,0
83,0
12,0
46346
–
14,0
26,0
83,0
14,0
46347
46518
16,0
32,0
92,0
16,0
46348
46519
18,0
32,0
92,0
18,0
46349
46520
20,0
38,0
104,0
20,0
46350
46521
25,0
38,0
104,0
25,0
46351
46522
METRIC
Z-Carb
• Unequal helix design
aids in damaging
harmonics by changing
the angle at which each
cutting edge enters and
exits the material
• Unequal flute spacing
helps to disrupt the
rhythmic pattern
created by the cutting
edge helping to
suppress damaging
harmonics
• Optimal material
removal rates through
increased feed and
depths of cut
• Ball nose design ideal
for finishing operations
in complex workpieces
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
4
TOLERANCES
(mm)
3–6
DIAMETER
D
1
=
+0,000/–0,030
D
2
=
h
6
BALL RADIUS
+0,000/–0,015
>6–10
DIAMETER
D
1
=
+0,000/–0,040
D
2
=
h
6
BALL RADIUS
+0,000/–0,020
>10–25
DIAMETER
D
1
=
+0,000/–0,050
D
2
=
h
6
BALL RADIUS
+0,000/–0,025
For patent
information visit
www.ksptpatents.com
