48 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
48
www.kyocera-sgstool.com
Z16CR
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
TI-NAMITE-X
1/8
1/4
1-1/2
1/8
.015
36505
5/32
5/16
2
3/16
.015
36506
3/16
3/8
2
3/16
.015
36507
7/32
3/8
2
1/4
.020
36508
1/4
7/16
2
1/4
.020
36509
5/16
1/2
2
5/16
.020
36511
3/8
5/8
2
3/8
.020
36513
7/16
5/8
2-1/2
7/16
.020
36515
1/2
5/8
2-1/2
1/2
.030
36517
5/8
3/4
3
5/8
.040
36519
3/4
1
3
3/4
.040
36520
END MILLS
END MILLS
FRACTIONAL
Z-Carb
• Unequal helix design
aids in damaging
harmonics by changing
the angle at which each
cutting edge enters and
exits the material
• Unequal flute spacing
helps to disrupt the
rhythmic pattern created
by the cutting edge
helping to suppress
damaging harmonics
• Optimal material removal
rates through increased
feed and depths of cut
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
4
TOLERANCES
(inch)
1/8–1/4
DIAMETER
D
1
=
+0.0000/–0.0012
D
2
=
h
6
R =
+0.0000/–0.005
>1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.0016
D
2
=
h
6
R =
+0.0000/–0.005
>3/8–3/4
DIAMETER
D
1
=
+0.0000/–0.0020
D
2
=
h
6
R =
+0.0000/–0.005
For patent
information visit
www.ksptpatents.com
