Z-Carb
Series
Z1M, Z1MB
Metric
Hardness
Ap
Ae
Ae
Vc
(m/min)
Diameter (D
1
)
(mm)
Ae x D
1
Ap x D
1
3
6
8
10
12
16
20
25
M
STAINLESS STEELS
(DIFFICULT)
304, 304L, 316, 316L
≤ 275 Bhn
or
≤ 28 HRc
Profile
≤ 0.5
≤ 1.5
104
RPM 10987 5493 4120 3296 2747 2060 1648 1318
(83-124)
Fz
0.005 0.014 0.023 0.029 0.034 0.046 0.051 0.050
Feed (mm/min) 211
316
387
387
369
380
334
264
Slot
1
≤ 1
82
RPM 8725 4362 3272 2617 2181 1636 1309 1047
(66-99)
Fz
0.005 0.014 0.023 0.029 0.034 0.046 0.051 0.050
Feed (mm/min) 168
251
307
307
293
302
265
209
STAINLESS STEELS
(PH)
13-8 PH, 15-5 PH,
17-4 PH, Custom 450
≤ 325 Bhn
or
≤ 35 HRc
Profile
≤ 0.5
≤ 1.5
94
RPM 10017 5009 3756 3005 2504 1878 1503 1202
(76-113)
Fz
0.005 0.014 0.023 0.029 0.034 0.046 0.051 0.050
Feed (mm/min) 192
288
353
353
337
346
305
240
Slot
1
≤ 1
76
RPM 8078 4039 3029 2424 2020 1515 1212
969
(61-91)
Fz
0.005 0.014 0.023 0.029 0.034 0.046 0.051 0.050
Feed (mm/min) 155
233
284
284
271
279
246
194
S
SUPER ALLOYS
(NICKEL, COBALT,
IRON BASE)
Inconel 601, 617, 625,
Incoloy, Monel 400
≤ 300 Bhn
or
≤ 32 HRc
Profile
≤ 0.5
≤ 1.5
24
RPM 2585 1293
969
776
646
485
388
310
(20-29)
Fz
0.005 0.010 0.017 0.021 0.024 0.033 0.037 0.038
Feed (mm/min)
55
50
66
53
62
65
58
47
Slot
1
≤ 1
20
RPM 2100 1050
788
630
525
394
315
252
(16-24)
Fz
0.005 0.010 0.017 0.021 0.024 0.033 0.037 0.038
Feed (mm/min)
40
40
54
54
50
52
47
38
SUPER ALLOYS
(NICKEL, COBALT,
IRON BASE)
Inconel 718, X-750,
Incoloy, Waspaloy,
Hastelloy, Rene
≤ 400 Bhn
or
≤ 43 HRc
Profile
≤ 0.5
≤ 1.5
19
RPM 2003 1002
751
601
501
376
301
240
(15-23)
Fz
0.002 0.007 0.011 0.013 0.017 0.020 0.024 0.025
Feed (mm/min)
19
29
32
32
34
31
29
24
Slot
1
≤ 1
15
RPM 1583
792
594
475
396
297
238
190
(12-18)
Fz
0.002 0.007 0.011 0.013 0.017 0.020 0.024 0.025
Feed (mm/min)
15
23
25
25
27
24
23
19
TITANIUM ALLOYS
Pure Titanium,
Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si
≤ 350 Bhn
or
≤ 38 HRc
Profile
≤ 0.5
≤ 1.5
66
RPM 6947 3474 2605 2084 1737 1303 1042
834
(52-79)
Fz
0.005 0.012 0.021 0.027 0.031 0.041 0.045 0.045
Feed (mm/min) 133
167
222
222
217
213
189
150
Slot
1
≤ 1
52
RPM 5493 2747 2060 1648 1373 1030
824
659
(41-62)
Fz
0.005 0.012 0.021 0.027 0.031 0.041 0.045 0.045
Feed (mm/min) 105
132
176
176
171
169
149
119
TITANIUM ALLOYS
(DIFFICULT)
Ti10Al2Fe3Al,
Ti5Al5V5Mo3Cr,
Ti7Al4Mo,
Ti3Al8V6Cr4Zr4Mo,
Ti6Al6V6Sn,
Ti15V3 Cr3Sn3Al
≤ 440 Bhn
or
≤ 47 HRc
Profile
≤ 0.5
≤ 1.5
23
RPM 2424 1212
909
727
606
454
364
291
(18-27)
Fz
0.005 0.012 0.021 0.027 0.031 0.041 0.045 0.045
Feed (mm/min)
47
58
78
78
76
74
66
52
Slot
1
≤ 1
18
RPM 1939
969
727
582
485
364
291
233
(15-22)
Fz
0.005 0.012 0.021 0.027 0.031 0.041 0.045 0.045
Feed (mm/min)
37
47
62
62
60
60
53
42
Bhn (Brinell) HRc (Rockwell C)
rpm = (Vc x 1000) / (D
1
x 3.14)
ipm = Fz x 4 x rpm
reduce speed and feed for materials harder than listed
reduce feed and Ae when finish milling (.02 x D
1
maximum)
refer to the KYOCERA SGS Tool Wizard
®
for complete technical information (www.kyocera-sgstool.com)
