END MILLS
END MILLS
www.kyocera-sgstool.com
Series
ZH1MCRS, ZH1MCR
Metric
Hardness
Ap
Ae
Ae
Vc
(m/min)
Diameter (D
1
)
(mm)
Ae x D
1
Ap x D
1
6
10
12
20
S
SUPER ALLOYS
(NICKEL, COBALT,
IRON BASE)
Inconel 601, 617, 625,
Incoloy, Monel 400
≤ 300 Bhn
or
≤ 32 HRc
Profile
≤ 0.5
≤ 1.5
26
RPM
1373
824
687
412
(21-31)
Fz
0.017
0.032
0.041
0.053
Feed (mm/min)
93
105
113
87
Slot
1
≤ 1
21
RPM
1131
679
565
339
(17-26)
Fz
0.017
0.032
0.041
0.053
Feed (mm/min)
77
87
93
72
SUPER ALLOYS
(NICKEL, COBALT,
IRON BASE)
Inconel 718, X-750,
Incoloy, Waspaloy,
Hastelloy, Rene
≤ 400 Bhn
or
≤ 43 HRc
Profile
≤ 0.5
≤ 1.5
21
RPM
1131
679
565
339
(17-26)
Fz
0.012
0.024
0.029
0.037
Feed (mm/min)
54
65
66
50
Slot
1
≤ 1
17
RPM
889
533
444
267
(13-20)
Fz
0.012
0.024
0.029
0.037
Feed (mm/min)
43
51
52
39
TITANIUM ALLOYS
Pure Titanium, Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si
≤ 350 Bhn
or
≤ 38 HRc
Profile
≤ 0.5
≤ 1.5
66
RPM
3474
2084
1737
1042
(52-79)
Fz
0.019
0.041
0.049
0.057
Feed (mm/min)
264
342
340
238
Slot
1
≤ 1
52
RPM
2747
1648
1373
824
(41-62)
Fz
0.019
0.041
0.049
0.057
Feed (mm/min)
209
270
269
188
TITANIUM ALLOYS
(DIFFICULT)
Ti10Al2Fe3Al,
Ti5Al5V5Mo3Cr, Ti7Al4Mo,
Ti3Al8V6Cr4Zr4Mo,
Ti6Al6V6Sn, Ti15V3
Cr3Sn3Al
≤ 440 Bhn
or
≤ 47 HRc
Profile
≤ 0.5
≤ 1.5
23
RPM
1212
727
606
364
(18-27)
Fz
0.019
0.041
0.049
0.057
Feed (mm/min)
92
119
119
83
Slot
1
≤ 1
18
RPM
969
582
485
291
(15-22)
Fz
0.019
0.041
0.049
0.057
Feed (mm/min)
74
95
95
66
Bhn (Brinell) HRc (Rockwell C)
rpm = (Vc x 1000) / (D
1
x 3.14)
ipm = Fz x 4 x rpm
reduce speed and feed for materials harder than listed
reduce feed and Ae when finish milling (.02 x D
1
maximum)
refer to the KYOCERA SGS Tool Wizard
®
for complete technical information (www.kyocera-sgstool.com)
METRIC
Z-Carb-HTA
