HARDENEDSTEELS
60
www.kyocera-sgstool.com
END MILLS
END MILLS
ZD1CR
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
Ti-NAMITE-X
1/8
5/32
2-1/2
1/4
1/2
.010
36780
3/16
7/32
2-1/2
1/4
3/4
.020
36781
1/4
9/32
2-1/2
1/4
3/4
.020
36782
5/16
13/32
2-1/2
5/16
1
.040
36783
3/8
15/32
2-1/2
3/8
1
.040
36784
7/16
9/16
2-3/4
7/16
1
.040
36785
1/2
5/8
3
1/2
1-1/4
.040
36786
1/2
5/8
4-1/2
1/2
2-1/4
.040
36787
5/8
3/4
3-1/2
5/8
1-1/2
.040
36788
5/8
3/4
4-1/2
5/8
2-1/4
.040
36789
5/8
3/4
5-1/2
5/8
3-1/4
.040
36790
3/4
15/16
4
3/4
1-3/4
.060
36791
3/4
15/16
4-1/2
3/4
2-1/4
.060
36792
3/4
15/16
5-1/2
3/4
3-1/4
.060
36793
FRACTIONAL
Z-Carb-MD
≠
NEG
4
TOLERANCES
(inch)
1/8–1/4
DIAMETER
D
1
=
+0.0000/–0.0012
D
2
=
h
6
R =
+0.0000/–0.0020
>1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.0016
D
2
=
h
6
R =
+0.0000/–0.0020
>3/8–3/4
DIAMETER
D
1
=
+0.0000/–0.0020
D
2
=
h
6
R =
+0.0000/–0.0020
• The original Z-Carb
design with negative
rake, heavy core, and
higher helix for strength
and shearing of hard
mold & die materials
• Unequal helix design
aids in damaging
harmonics by changing
the angle at which each
cutting edge enters and
exits the material
• Unequal flute spacing
helps to disrupt the
rhythmic pattern created
by the cutting edge
helping to suppress
damaging harmonics
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials 35-60HRc
(327 to 654 Bhn)
For patent
information visit
www.ksptpatents.com
