188 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
188
www.kyocera-sgstool.com
5
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/64
1/32
1-1/2
1/8
30501
39701
30771
30811
1/32
5/64
1-1/2
1/8
30503
39703
30772
30812
3/64
7/64
1-1/2
1/8
30505
39705
30773
30813
1/16
3/16
1-1/2
1/8
30507
39707
30774
30814
5/64
3/16
1-1/2
1/8
30509
39709
30775
30815
3/32
9/32
1-1/2
1/8
30511
39711
30776
30816
7/64
3/8
1-1/2
1/8
30513
39713
30777
30817
1/8
3/8
1-1/2
1/8
30577
39777
30809
30849
1/8
1/2
1-1/2
1/8
30515
39715
30778
30818
9/64
1/2
2
3/16
30517
39717
30779
30819
5/32
1/2
2
3/16
30519
39719
30780
30820
11/64
5/8
2
3/16
30521
39721
30781
30821
3/16
5/8
2
3/16
30523
39723
30782
30822
13/64
5/8
2-1/2
1/4
30525
39725
30783
30823
7/32
5/8
2-1/2
1/4
30527
39727
30784
30824
15/64
3/4
2-1/2
1/4
30529
39729
30785
30825
1/4
3/4
2-1/2
1/4
30531
39731
30786
30826
17/64
3/4
2-1/2
5/16
30533
39733
30787
30827
9/32
3/4
2-1/2
5/16
30535
39735
30788
30828
19/64
13/16
2-1/2
5/16
30537
39737
30789
30829
5/16
13/16
2-1/2
5/16
30539
39739
30790
30830
21/64
1
2-1/2
3/8
30541
39741
30791
30831
11/32
1
2-1/2
3/8
30543
39743
30792
30832
23/64
1
2-1/2
3/8
30545
39745
30793
30833
3/8
1
2-1/2
3/8
30547
39747
30794
30834
25/64
1
2-3/4
7/16
30549
39749
30795
30835
13/32
1
2-3/4
7/16
30551
39751
30796
30836
27/64
1
2-3/4
7/16
30553
39753
30797
30837
7/16
1
2-3/4
7/16
30555
39755
30798
30838
29/64
1
3
1/2
30557
39757
30799
30839
15/32
1
3
1/2
30559
39759
30800
30840
31/64
1
3
1/2
30561
39761
30801
30841
1/2
1
3
1/2
30563
39763
30802
30842
9/16
1-1/8
3-1/2
9/16
30565
39765
30803
30843
5/8
1-1/4
3-1/2
5/8
30567
39767
30804
30844
11/16
1-3/8
4
3/4
30569
39769
30805
30845
3/4
1-1/2
4
3/4
30571
39771
30806
30846
7/8
1-1/2
4
7/8
30573
39773
30807
30847
1
1-1/2
4
1
30575
39775
30808
30848
FRACTIONAL
3 Flute Square End
POS
3
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
