191 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
191
www.kyocera-sgstool.com
24
FRACTIONAL SERIES
inch
EDP NO.
SHANK
DIAMETER
D
2
CENTER LINE
ANGLE
α
RADIUS
R
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/4
1°
0.062
1-1/2
3
32402
32403
32445
32470
1/4
1°30'
0.062
1-1/2
3
32404
32405
32446
32471
1/4
2°
0.062
1-1/4
3
32406
32407
32447
32472
1/4
3°
0.062
1
3
32408
32409
32448
32473
1/4
5°
0.062
3/4
3
32410
32411
32449
32474
1/4
7°
0.062
1/2
3
32412
32413
32450
32475
1/4
10°
0.047
1/2
3
32414
32415
32451
32476
3/8
1°
0.093
1-3/4
3-1/2
32416
32417
32452
32477
3/8
1°30'
0.093
1-3/4
3-1/2
32418
32419
32453
32478
3/8
2°
0.093
1-3/4
3-1/2
32420
32421
32454
32479
3/8
3°
0.078
1-3/4
3-1/2
32422
32423
32455
32480
3/8
5°
0.062
1-1/2
3-1/2
32424
32425
32456
32481
3/8
7°
0.062
1
3-1/2
32426
32427
32457
32482
3/8
10°
0.062
3/4
3-1/2
32428
32429
32458
32483
1/2
1°
0.125
2
4
32430
32431
32459
32484
1/2
2°
0.125
2
4
32434
32435
32460
32485
1/2
3°
0.125
2
4
32436
32437
32461
32486
1/2
5°
0.125
1-1/4
4
32438
32439
32462
32487
1/2
7°
0.093
1-1/4
4
32440
32441
32463
32488
1/2
10°
0.062
1
4
32442
32443
32464
32489
FRACTIONAL
Tapered Radius End
POS
3
For patent
information visit
www.ksptpatents.com
TOLERANCES
(inch)
D
2
=
h
6
R =
+0.0005/–0.0010
