214 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
214
www.kyocera-sgstool.com
3M
•
3XLM
METRIC SERIES
mm
EDP NO.
SERIES
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1,0
4,0
38,0
3,0
40305
48628
48650
48671
3M
1,5
4,5
38,0
3,0
40309
48629
48651
48672
3M
2,0
6,3
38,0
3,0
40313
48630
48652
48673
3M
2,5
9,5
38,0
3,0
40317
48631
48653
48674
3M
3,0
12,0
38,0
3,0
40321
48632
48654
48675
3M
3,0
25,0
75,0
3,0
43301
49427
49440
49453 3XLM
3,5
12,0
50,0
4,0
40325
48633
48655
48676
3M
4,0
14,0
50,0
4,0
40329
48634
48656
48677
3M
4,0
25,0
75,0
4,0
43303
49428
49441
49454 3XLM
4,5
16,0
50,0
6,0
40333
48635
48657
48678
3M
5,0
16,0
50,0
6,0
40337
48636
48658
48679
3M
5,0
25,0
75,0
5,0
43307
49430
49443
49456 3XLM
6,0
19,0
50,0
6,0
40341
48637
48659
48680
3M
6,0
25,0
75,0
6,0
43305
49429
49442
49455 3XLM
7,0
19,0
63,0
8,0
40345
48638
48660
48681
3M
8,0
20,0
63,0
8,0
40349
48639
48661
48682
3M
8,0
25,0
75,0
8,0
43315
49431
49444
49457 3XLM
9,0
22,0
75,0
10,0
40353
48640
48662
48683
3M
10,0
22,0
75,0
10,0
40357
48641
48663
48684
3M
10,0
38,0
100,0
10,0
43325
49432
49445
49458 3XLM
11,0
25,0
75,0
12,0
40361
48642
48664
48685
3M
12,0
25,0
75,0
12,0
40365
48643
48665
48686
3M
12,0
50,0
100,0
12,0
43335
49433
49446
49459 3XLM
12,0
75,0
150,0
12,0
43345
49434
49447
49460 3XLM
14,0
32,0
89,0
14,0
40369
48644
48666
48687
3M
14,0
75,0
150,0
14,0
43355
49435
49448
49461 3XLM
16,0
32,0
89,0
16,0
40373
48645
48667
48688
3M
16,0
75,0
150,0
16,0
43365
49436
49449
49462 3XLM
18,0
38,0
100,0
18,0
40377
48646
48668
48689
3M
18,0
75,0
150,0
18,0
43375
49437
49450
49463 3XLM
20,0
38,0
100,0
20,0
40381
48647
48669
48690
3M
20,0
75,0
150,0
20,0
43385
49438
49451
49464 3XLM
25,0
38,0
100,0
25,0
40385
48648
48670
48691
3M
25,0
75,0
150,0
25,0
43395
49439
49452
49465 3XLM
METRIC
2 Flute Square End
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
POS
2
