213 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
213
www.kyocera-sgstool.com
17M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1,0
2,0
38,0
3,0
41705
49262
49283
49304
1,5
3,0
38,0
3,0
41709
49263
49284
49305
2,0
4,0
38,0
3,0
41713
49264
49285
49306
2,5
5,0
38,0
3,0
41717
49265
49286
49307
3,0
6,0
38,0
3,0
41721
49266
49287
49308
3,5
7,0
50,0
4,0
41725
49267
49288
49309
4,0
8,0
50,0
4,0
41729
49268
49289
49310
4,5
9,5
50,0
4,5
41733
49269
49290
49311
5,0
10,0
50,0
5,0
41737
49270
49291
49312
6,0
12,0
50,0
6,0
41741
49271
49292
49313
7,0
12,0
50,0
8,0
41745
49272
49293
49314
8,0
12,0
50,0
8,0
41749
49273
49294
49315
9,0
14,0
50,0
9,0
41753
49274
49295
49316
10,0
16,0
50,0
10,0
41757
49275
49296
49317
11,0
19,0
63,0
12,0
41761
49276
49297
49318
12,0
19,0
63,0
12,0
41765
49277
49298
49319
METRIC
2 Flute Square End Stub
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
POS
2
For patent
information visit
www.ksptpatents.com
