59M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
3,0
9,0
60,0
6,0
43910
43920
43930
43950
4,0
12,0
70,0
6,0
43911
43921
43931
43951
6,0
15,0
80,0
6,0
43912
43922
43932
43952
8,0
20,0
89,0
8,0
43913
43923
43933
43953
10,0
25,0
100,0
10,0
43914
43924
43934
43954
12,0
30,0
110,0
12,0
43915
43925
43935
43955
14,0
35,0
120,0
16,0
43916
43926
43936
43956
16,0
40,0
120,0
16,0
43917
43927
43937
43957
18,0
40,0
130,0
20,0
43918
43928
43938
43958
20,0
45,0
130,0
20,0
43919
43929
43939
43959
Neck Option Available
METRIC
2 Flute Square End Long Reach
POS
2
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
