219 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
219
www.kyocera-sgstool.com
15MB
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1,0
2,0
38,0
3,0
41506
49073
49094
49115
1,5
3,0
38,0
3,0
41510
49074
49095
49116
2,0
4,0
38,0
3,0
41514
49075
49096
49117
2,5
5,0
38,0
3,0
41518
49076
49097
49118
3,0
6,0
38,0
3,0
41522
49077
49098
49119
3,5
7,0
50,0
4,0
41526
49078
49099
49120
4,0
8,0
50,0
4,0
41530
49079
49100
49121
4,5
9,5
63,0
4,5
41534
49080
49101
49122
5,0
10,0
63,0
5,0
41538
49081
49102
49123
6,0
12,0
63,0
6,0
41542
49082
49103
49124
7,0
12,0
63,0
8,0
41546
49083
49104
49125
8,0
12,0
63,0
8,0
41550
49084
49105
49126
9,0
14,0
75,0
9,0
41554
49085
49106
49127
10,0
14,0
75,0
10,0
41558
49086
49107
49128
11,0
14,0
75,0
12,0
41562
49087
49108
49129
12,0
16,0
75,0
12,0
41566
49088
49109
49130
METRIC
2 Flute Double End Ball End
POS
2
For patent
information visit
www.ksptpatents.com
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
BALL RADIUS
+0,000/–0,025
