43 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
43
www.kyocera-sgstool.com
END MILLS
END MILLS
Z1MPIC
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
Ti-NAMITE-X
W/FLAT
12,0
26,0
83,0
12,0
36,0
2,5
42731
12,0
26,0
83,0
12,0
36,0
3,0
42732
12,0
26,0
83,0
12,0
36,0
4,0
42733
16,0
32,0
92,0
16,0
42,0
2,5
42734
16,0
32,0
92,0
16,0
42,0
4,0
42735
16,0
32,0
92,0
16,0
42,0
6,0
42736
20,0
38,0
104,0
20,0
52,0
2,5
42737
20,0
38,0
104,0
20,0
52,0
4,0
42738
20,0
38,0
104,0
20,0
52,0
6,0
42739
METRIC
Z-Carb-AP
For patent
information visit
www.ksptpatents.com
≠
≠
4
• Variable rake geometry
alters and controls the
cutting dynamic taking
chatter suppression to
an unprecedented level
• Unequal helix design
changes the cutting
angle to improve
harmonics
• Unequal flute spacing
helps to disrupt the
rhythmic pattern
created by the cutting
edge helping to
suppress damaging
harmonics
• Long reach design
allows for deeper and
faster cuts
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
TOLERANCES
(mm)
>12–20
DIAMETER
D
1
=
+0,000/–0,050
D
2
=
h
6
R =
+0,000/–0,050
