Z-Carb-AP
Series
Z1MPCR, Z1MPIC,
Z1MPLC
Metric
Hardness
Ap
Ae
Ae
Vc
(m/min)
Diameter (D
1
)
(mm)
Ae x D
1
Ap x D
1
1
3
6
8
10 12 16 20 25
P
CARBON STEELS
1018, 1040, 1080,
1090, 10L50, 1140,
1212, 12L15, 1525,
1536
≤ 275 Bhn
or
≤ 28 HRc
Profile
≤ 0.5
≤ 1.5
169
RPM 53803 17934 8967 6725 5380 4484 3363 2690 2152
(135-203)
Fz
0.0030 0.0109 0.029 0.049 0.061 0.074 0.087 0.099 0.108
Feed (mm/min) 646 782 1040 1318 1313 1327 1170 1065 930
Slot
1
≤ 1
134
RPM 42654 14218 7109 5332 4265 3555 2666 2133 1706
(107-161)
Fz
0.0030 0.0109 0.029 0.049 0.061 0.074 0.087 0.099 0.108
Feed (mm/min) 512 620 825 1045 1041 1052 928 845 737
ALLOY STEELS
4140, 4150, 4320,
5120, 5150, 8630,
86L20, 50100
≤ 375 Bhn
or
≤ 40 HRc
Profile
≤ 0.5
≤ 1.5
96
RPM 30537 10179 5089 3817 3054 2545 1909 1527 1221
(77-115)
Fz
0.0023 0.0081 0.022 0.036 0.045 0.055 0.067 0.075 0.080
Feed (mm/min) 281 330 448 550 550 560 511 458 391
Slot
1
≤ 1
76
RPM 24235 8078 4039 3029 2424 2020 1515 1212 969
(61-91)
Fz
0.0023 0.0081 0.022 0.036 0.045 0.055 0.067 0.075 0.080
Feed (mm/min) 223 262 355 436 436 444 406 364 310
H
TOOL STEELS
A2, D2, H13, L2, M2,
P20, S7, T15, W2
≤ 375 Bhn
or
≤ 40 HRc
Profile
≤ 0.5
≤ 1.5
56
RPM 17934 5978 2989 2242 1793 1495 1121 897 717
(45-68)
Fz
0.0018 0.0066 0.017 0.030 0.037 0.043 0.051 0.059 0.065
Feed (mm/min) 129 158 203 269 265 257 229 212 187
Slot
1
≤ 1
44
RPM 14057 4686 2343 1757 1406 1171 879 703 562
(35-53)
Fz
0.0018 0.0066 0.017 0.030 0.037 0.043 0.051 0.059 0.065
Feed (mm/min) 101 124 159 211 208 201 179 166 146
K
CAST IRONS
(LOW & MEDIUM
ALLOY)
Gray, Malleable,
Ductile
≤ 220 Bhn
or
≤ 19 HRc
Profile
≤ 0.5
≤ 1.5
136
RPM 43139 14380 7190 5392 4314 3595 2696 2157 1726
(109-163)
Fz
0.0028 0.0099 0.026 0.045 0.056 0.067 0.079 0.091 0.098
Feed (mm/min) 483 569 748 971 966 963 852 785 676
Slot
1
≤ 1
108
RPM 34414 11471 5736 4302 3441 2868 2151 1721 1377
(87-130)
Fz
0.0028 0.0099 0.026 0.045 0.056 0.067 0.079 0.091 0.098
Feed (mm/min) 385 454 597 774 771 769 680 626 540
CAST IRONS
(HIGH ALLOY)
Gray, Malleable,
Ductile
≤ 260 Bhn
or
≤ 26 HRc
Profile
≤ 0.5
≤ 1.5
104
RPM 32960 10987 5493 4120 3296 2747 2060 1648 1318
(83-124)
Fz
0.0020 0.0074 0.020 0.034 0.043 0.050 0.059 0.067 0.074
Feed (mm/min) 264 325 439 560 567 549 486 442 390
Slot
1
≤ 1
82
RPM 26174 8725 4362 3272 2617 2181 1636 1309 1047
(66-99)
Fz
0.0020 0.0074 0.020 0.034 0.043 0.050 0.059 0.067 0.074
Feed (mm/min) 209 258 349 445 450 436 386 351 310
M
STAINLESS STEELS
(FREE MACHINING)
303, 416, 420F,
430F, 440F
≤ 275 Bhn
or
≤ 28 HRc
Profile
≤ 0.5
≤ 1.5
149
RPM 47501 15834 7917 5938 4750 3958 2969 2375 1900
(119-179)
Fz
0.0023 0.0081 0.022 0.036 0.045 0.055 0.067 0.075 0.080
Feed (mm/min) 437 513 697 855 855 871 796 713 608
Slot
1
≤ 1
119
RPM 37807 12602 6301 4726 3781 3151 2363 1890 1512
(95-143)
Fz
0.0023 0.0081 0.022 0.036 0.045 0.055 0.067 0.075 0.080
Feed (mm/min) 348 408 555 681 681 693 633 567 484
