STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
189
www.kyocera-sgstool.com
5B
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/64
1/32
1-1/2
1/8
30502
30851
30602
31130
1/32
5/64
1-1/2
1/8
30504
30852
30604
31131
3/64
7/64
1-1/2
1/8
30506
30853
30606
31132
1/16
3/16
1-1/2
1/8
30508
30854
30608
31133
5/64
3/16
1-1/2
1/8
30510
30855
30610
31134
3/32
9/32
1-1/2
1/8
30512
30856
30612
31135
7/64
3/8
1-1/2
1/8
30514
30857
30902
31136
1/8
3/8
1-1/2
1/8
30578
30889
30943
31168
*1/8
1/2
1-1/2
1/8
30516
30858
30904
31137
9/64
1/2
2
3/16
30518
30859
30906
31138
5/32
1/2
2
3/16
30520
30860
30908
31139
11/64
5/8
2
3/16
30522
30861
30910
31140
*3/16
5/8
2
3/16
30524
30862
30912
31141
13/64
5/8
2-1/2
1/4
30526
30863
30914
31142
7/32
5/8
2-1/2
1/4
30528
30864
30916
31143
15/64
3/4
2-1/2
1/4
30530
30865
30918
31144
1/4
3/4
2-1/2
1/4
30532
30866
30920
31145
17/64
3/4
2-1/2
5/16
30534
30867
30921
31146
9/32
3/4
2-1/2
5/16
30536
30868
30922
31147
19/64
13/16
2-1/2
5/16
30538
30869
30923
31148
*5/16
13/16
2-1/2
5/16
30540
30870
30924
31149
21/64
1
2-1/2
3/8
30542
30871
30925
31150
11/32
1
2-1/2
3/8
30544
30872
30926
31151
23/64
1
2-1/2
3/8
30546
30873
30927
31152
*3/8
1
2-1/2
3/8
30548
30874
30928
31153
25/64
1
2-3/4
7/16
30550
30875
30929
31154
13/32
1
2-3/4
7/16
30552
30876
30930
31155
27/64
1
2-3/4
7/16
30554
30877
30931
31156
7/16
1
2-3/4
7/16
30556
30878
30932
31157
29/64
1
3
1/2
30558
30879
30933
31158
15/32
1
3
1/2
30560
30880
30934
31159
31/64
1
3
1/2
30562
30881
30935
31160
*1/2
1
3
1/2
30564
30882
30936
31161
9/16
1-1/8
3-1/2
9/16
30566
30883
30937
31162
5/8
1-1/4
3-1/2
5/8
30568
30884
30938
31163
11/16
1-3/8
4
3/4
30570
30885
30939
31164
3/4
1-1/2
4
3/4
30572
30886
30940
31165
7/8
1-1/2
4
7/8
30574
30887
30941
31166
1
1-1/2
4
1
30576
30888
30942
31167
*Series 5B Set
30590
30900
30944
31169
FRACTIONAL
3 Flute Ball End
POS
3
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0010
For patent
information visit
www.ksptpatents.com
