190 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
190
www.kyocera-sgstool.com
23
FRACTIONAL SERIES
inch
EDP NO.
SHANK
DIAMETER
D
2
CENTER LINE
ANGLE
α
SMALL
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/4
1°
1/8
1-1/2
3
32301
32370
32302
32345
1/4
1°30'
1/8
1-1/2
3
32303
32371
32304
32346
1/4
2°
1/8
1-1/4
3
32305
32372
32306
32347
1/4
3°
1/8
1
3
32307
32373
32308
32348
1/4
5°
1/8
3/4
3
32309
32374
32310
32349
1/4
7°
1/8
1/2
3
32311
32375
32312
32350
1/4
10°
3/32
1/2
3
32313
32376
32314
32351
3/8
1°
3/16
1-3/4
3-1/2
32315
32377
32316
32352
3/8
1°30'
3/16
1-3/4
3-1/2
32317
32378
32318
32353
3/8
2°
3/16
1-3/4
3-1/2
32319
32379
32320
32354
3/8
3°
5/32
1-3/4
3-1/2
32321
32380
32322
32355
3/8
5°
1/8
1-1/2
3-1/2
32323
32381
32324
32356
3/8
7°
1/8
1
3-1/2
32325
32382
32326
32357
3/8
10°
1/8
3/4
3-1/2
32327
32383
32328
32358
1/2
1°
1/4
2
4
32329
32384
32330
32359
1/2
2°
1/4
2
4
32333
32385
32334
32360
1/2
3°
1/4
2
4
32335
32386
32336
32361
1/2
5°
1/4
1-1/4
4
32337
32387
32338
32362
1/2
7°
3/16
1-1/4
4
32339
32388
32340
32363
1/2
10°
1/8
1
4
32341
32389
32342
32364
FRACTIONAL
Tapered Square End
POS
3
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
