216 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
216
www.kyocera-sgstool.com
15M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1,0
2,0
38,0
3,0
41505
49010
49031
49052
1,5
3,0
38,0
3,0
41509
49011
49032
49053
2,0
4,0
38,0
3,0
41513
49012
49033
49054
2,5
5,0
38,0
3,0
41517
49013
49034
49055
3,0
6,0
38,0
3,0
41521
49014
49035
49056
3,5
7,0
50,0
4,0
41525
49015
49036
49057
4,0
8,0
50,0
4,0
41529
49016
49037
49058
4,5
9,5
63,0
4,5
41533
49017
49038
49059
5,0
10,0
63,0
5,0
41537
49018
49039
49060
6,0
12,0
63,0
6,0
41541
49019
49040
49061
7,0
12,0
63,0
8,0
41545
49020
49041
49062
8,0
12,0
63,0
8,0
41549
49021
49042
49063
9,0
14,0
75,0
9,0
41553
49022
49043
49064
10,0
14,0
75,0
10,0
41557
49023
49044
49065
11,0
14,0
75,0
12,0
41561
49024
49045
49066
12,0
16,0
75,0
12,0
41565
49025
49046
49067
METRIC
2 Flute Double End Mills
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
POS
2
For patent
information visit
www.ksptpatents.com
