59MB
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
3,0
9,0
60,0
6,0
43900
49622
49632
49642
4,0
12,0
70,0
6,0
43901
49623
49633
49643
6,0
15,0
80,0
6,0
43902
49624
49634
49644
8,0
20,0
89,0
8,0
43903
49625
49635
49645
10,0
25,0
100,0
10,0
43904
49626
49636
49646
12,0
30,0
110,0
12,0
43905
49627
49637
49647
14,0
35,0
120,0
16,0
43906
49628
49638
49648
16,0
40,0
120,0
16,0
43907
49629
49639
49649
18,0
40,0
130,0
20,0
43908
49630
49640
49650
20,0
45,0
130,0
20,0
43909
49631
49641
49651
Neck Option Available
METRIC
2 Flute Ball End Long Reach
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
BALL RADIUS
+0,000/–0,025
POS
2
