47 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
47
www.kyocera-sgstool.com
END MILLS
END MILLS
Z1
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-A
(AlTiN)
Ti-NAMITE-A
(AlTiN)
W/FLAT
JetStream
1/8
3/8
1-1/2
1/8
36404
–
–
5/32
7/16
2
3/16
36406
–
–
3/16
7/16
2
3/16
36408
–
–
7/32
7/16
2-1/2
1/4
36410
–
–
1/4
1/2
2-1/2
1/4
36416
–
–
1/4
3/4
2-1/2
1/4
36596
–
–
9/32
5/8
2-1/2
5/16
36418
–
–
5/16
13/16
2-1/2
5/16
36420
–
–
11/32
13/16
2-1/2
3/8
36422
–
–
3/8
7/8
2-1/2
3/8
36424
36530
–
13/32
15/16
2-3/4
7/16
36426
36531
–
7/16
1
2-3/4
7/16
36428
36532
–
15/32
1
3
1/2
36430
36533
–
1/2
1
3
1/2
36432
36534
36826
1/2
1-1/4
3-1/4
1/2
36597
36598
–
9/16
1-1/8
3-1/2
9/16
36436
36535
36827
5/8
1-1/4
3-1/2
5/8
36440
36536
36828
3/4
1-1/2
4
3/4
36442
36537
36829
1
1-1/2
4
1
36444
36538
36830
FRACTIONAL
Z-Carb
• Unequal helix design
aids in damaging
harmonics by changing
the angle at which each
cutting edge enters and
exits the material
• Unequal flute spacing
helps to disrupt the
rhythmic pattern
created by the cutting
edge helping to
suppress damaging
harmonics
• Optimal material
removal rates through
increased feed and
depths of cut
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
4
TOLERANCES
(inch)
1/8–1/4
DIAMETER
D
1
=
+0.0000/–0.0012
D
2
=
h
6
>1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.0016
D
2
=
h
6
>3/8–1
DIAMETER
D
1
=
+0.0000/–0.0020
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
